Automatic High Speed 2 Shaft Paper Tube Cutting Machine

PPD-5A-1500

Automatic high speed 2 shaft paper tube cutting machine is design for cutting of all kinds of tubes in small pieces, such as chemical fibre tube, OPP film tube, Tape cores, etc.
It is suitable for cutting a large number shorter tubes and other tubes which cutting length is change frequently .

Feature:
1.Uses servo system to fixed position, high precise ball screw to transmit, the cutting precision can upto 0.01mm.
2.Machine works with two cutting shaft, for both cutting and unloading/loading tubes, so as to improve work efficiency.
3. PLC control, color touch screen man-machine operation.
4.Rotate speed of main shaft and speed of changing shaft is control by inverter.

Main data:

Name:Automatic High Speed 2 Shaft Paper Tube Cutting Machine

Model:PPD-5A-1500

Paper tube length:1500mm

Finish tube length:min3mm

Cutting thickness:1-15mm

Cutting diameter:25-180mm

Cutting speed:25m/min

Way of moving knife:pneumatic

Power supply:380V，4KW
