Cling Film Slitter Rewinder
You are here: > Home > Products > Cling Film Slitter Rewinder
2 Shaft PVC Cling Film Slitter Rewinder
PPD-CFSR500
2 shaft pvc cling film slitter rewinder integrates precise slitting, intelligent rewinding, electrostatic adsorption, hot wire cutting, and automatic finished product ejection. It is specifically designed for large-scale processing of cling film, creating an automated production line suitable for various food-grade cling films such as PE, PVC, and PVDC cling film.
Features:
1. Machine adopts a dual-station independent winding system, with one station for material transfer and winding, and the other for simultaneous operation, ensuring seamless, continuous operation and significantly improving efficiency.
2. Machine is equipped with an electrostatic adsorption device, ensuring tight and wrinkle-free film surface during rewinding, effectively preventing loose or misaligned film layers, resulting in a tight and flat finished roll.
3. Hot wire cutting replaces traditional blade cutting, resulting in a smooth, burr-free cut without adhesive residue, perfectly suited for various thicknesses of cling film.
4. After the product is slit and rewound to the preset length, the hot wire cutting is automatically triggered, and the finished product is automatically ejected.
Features:
1. Machine adopts a dual-station independent winding system, with one station for material transfer and winding, and the other for simultaneous operation, ensuring seamless, continuous operation and significantly improving efficiency.
2. Machine is equipped with an electrostatic adsorption device, ensuring tight and wrinkle-free film surface during rewinding, effectively preventing loose or misaligned film layers, resulting in a tight and flat finished roll.
3. Hot wire cutting replaces traditional blade cutting, resulting in a smooth, burr-free cut without adhesive residue, perfectly suited for various thicknesses of cling film.
4. After the product is slit and rewound to the preset length, the hot wire cutting is automatically triggered, and the finished product is automatically ejected.
Main Data:
Name:2 Shaft PVC Cling Film Slitter Rewinder
Model:PPD-CFSR500
Jumbo roll width:500mm
Jumbo roll ID:76mm
Jumbo roll OD:450mm
Rewind roll width:max500mm
Rewind roll ID:38/50/76mm option
Rewind roll OD:max180mm
Speed:0-100m/min
Voltage:220/380/415V,50Hz
Power:2.2kw
