2 Shaft Silicon Paper Baking Paper Rewinder

PPD-2BPR450

2 shaft silicon paper baking paper rewinder is a highly efficient and intelligent special equipment, mainly used for rewinding food paper, such as baking paper,silicon paper,wax paper,PE coated paper,bakery paper, non-stick paper, etc. Its core design is a double rewinding station, which supports alternating rewinding and seamless switching of double stations, significantly improving production efficiency and reducing downtime, and is suitable for continuous large-scale operations.

Features:
1. Unwinding system: The pneumatic shaft is used to fix the large roll of raw materials, equipped with automatic tension control to ensure smooth unwinding.
2. Rewinding station: Double-station rewinding design (A/B axis), after rewinding is completed, it automatically flips and switches to rewinding, and the maximum rewinding diameter can reach 120mm.
3. The machine is integrated and controlled by PLC+touch screen, real-time monitoring of speed, length and other parameters, and supports one-button operation of preset parameters.
4. Adjustable width, adjustable width 100-450mm, compatible with silicone oil paper of different specifications.

Technical Data:

Name: 2 Shaft Silicon Paper Baking Paper Rewinder

Model: PPD-2BPR450

Unwinding width: 100-450mm

Unwinding inner diameter: 3inch / 6inch optional

Unwinding outer diameter: maximum 600mm

Unwinding weight: maximum 200kg

Rewinding width: 100-450mm same as unwinding width

Rewinding outer diameter: maximum 120mm (adapted to paper tube inner diameter: 76mm/152mm)

Rewinding length: maximum 300 meters/roll

Rewinding speed: max150 meters/minute

Voltage: 220/380/415V, 50Hz

Power: 2.2kw
