Wallpaper Rewinder Machine

PPD-WP800

Wallpaper rewinder machine is mainly used for rewinding of various gift paper, color printing paper, wallpaper, cash register paper, baking paper and other materials.
It is automatic metering counting, automatic stop, automatic cutting of materials, PLC program control to accurately complete each automatic action, with frequency control to improve production efficiency, using magnetic powder tension to adjust material stability.

Features:

1. This machine adopts frequency conversion speed regulation to keep running smoothly during acceleration.

2. Automatic metering, automatic shutdown

3. Winding shaft structure is adopted for winding, convenient for loading and unloading

4. Pneumatic feeding with 3 inch air shaft

5. Unwinding tension adopts automatic tension

6. It has the functions of high fixed length precision, neat winding, easy operation, beautiful appearance and stable performance.

Main Technicial Data:

Name:Wallpaper Rewinder Machine

Model：PPD-WP800

Maximum diameter of jumbo roll:1000mm

Inner diameter of the jumbo roll: 76mm

Rewind roll maximum outer diameter:250mm

Maximum rewind width:800 mm

Rewinding speed:max200m/min

Rewind length: max100m

Rewind roll inner diameter: 25mm air shaft

Power supply： 4.5kw

Voltage: 380V, 50hz

Machine weight 800kg

Machine dimensions:1600 x 1500 x1600mm（LxWxH）

NOTE:Different sizes can be customized.
