High Speed Fully Automatic Stretch Film Rewinding Machine

PPD-HARW500

Machine is the latest model for high speed stretch film rewinder at 1500meter per minute.
Machine is increased wall frame thickness 20mm to machine stabilization during heavy duty production.
Automatic Stop when empty core – protect machine roller run with empty core
Auto stop when mother roll finished – reduce waste whereby new film can joint together easily continue run with previous balance roll length setting . At same time protect machine run without film at metal roller.
With above smart automation,the non-skilled operator required for the machine,one operator can run 3 machines at the same time!it save the labor cost a lot.
It adopts premium quality LCD monitor device,PLC programable logic controller,speed contorl by inverter.
It is very ideal of rewinding stretch film,and PE cling film,PVC cling film too.

Main specs:
Master reel width:500mm
Master reel ID:76mm
Master reel OD:500mm
Sub roll width:300-500mm
Sub roll ID:38/50/76mm
Sub roll OD:180mm
Machine design speed:max 1500m/min
Power:4kw
Weight:1.05 Ton
Volt:220/380/415/450v
