PVC Protective Film Slitter Rewinder

PPD-PFS500

PVC protective film slitter rewinder is used to separate large rolls of protetcive film packaging and wrapping film, which can divide the large rolls into multiple finished rolls of the same width.
Machine is suitable for slitting and rewinding plastic films such as wire film, stretch film, stretch film, cling film, and cast film.
The machine is convenient and flexible to adjust, low noise, frequency conversion speed regulation, automatic meter counting for rewinding, and easy to use.

Features:
1. The inverter control system is easy to operate and convenient to maintain.
2. The diameter of the reel paper tube is 1-3 inches, optional
3. Comes with slitting and rewinding function, which can slit any width.
4. Rewinding and unwinding are synchronized, no tension is generated, the machine runs smoothly, and the two sides of the film are symmetrical

Technical Data:

Name: PVC Protective Film Slitter Rewinder

Model: PPD-PFS500

Parent roll width: 50: mm

Material thickness: 7-50 micro

Diameter of parent roll: max400mm

Diameter of mother roll paper core: 76mm/3''

Product roll core diameter: 25/38/76mm option

Product roll length 5-300m

Speed: max600m/min

Power 4kw
