Automatic Stretch Film Rewinding Machine
PPD-ARW500-3L
Automatic stretch film rewinding machine is fully automatic, high speed rewinding for stretch film jumbo roll into small hand rolls,pallet rolls,machine rolls etc for easy use.
This model can combine 3 units into a production line in the same time.
In the production line,there are 2,3 or 4 machines work with conveyor belt,slide down table and up down driving carton sealer together to rewind the jumbo rolls into small rolls and then pack the finished product rolls into cartons.
This production line make the production more efficiency and save the labor cost.
Main Specs:
Name:Automatic Stretch Film Rewinding Machine
Model:PPD-ARW500-3L
Material:Stretch film,Cling film
Jumbo roll width:500mm
Jumbo roll ID:3inch
Jumbo roll OD:500mm
Rewind roll width:max500mm
Rewind roll ID:1.5/2/3inch
Rewind roll OD:180mm
Design speed:1500rpm/min
Power:3.7kw
Voltage:220/380/415V option
NOTE:Different sizes can be customized.
