Automatic Cling Film Rewinding Machine

PPD-ACW300

Automatic cling film rewinding machine is very standard model for rewinding of food cling film from the jumbo roll into small roll.
Machine works with PLC program and color touch screen design makes the operation very simple and smart.
By single shaft automatic changing into next core,the machine is able to reach the design speed at 900 meter per minute.
This model can rewind different length from 7 to 600m as buyer option.

Main data:
Name：Automatic cling film rewinding machine
Model:PPD-ACW300
Jumbo roll width:300mm
Jumbo roll inner diameter:3inch
Jumbo roll outer diameter:300mm
Rewind roll width:max450mm
Rewind roll inner diameter:1.5/2 /3inch
Rewind roll outer diameter:200mm
Design speed:900m/min
Power:4kw
Voltage:220/380/415V option
Pneumatic air need:0.3Mpa
NOTE:Different size can be customized.
